Blazor Radzen .NET 8 DataGrid InLineEdit
Blazor Radzen .NET 8 DataGrid InLineEdit
Blazor: Blazor
A framework for building interactive web applications using C# instead of JavaScript. It allows developers to create rich web UIs with a component-based architecture.
Radzen: Radzen
A set of UI components for Blazor that simplifies the development of web applications. It provides a variety of controls
, including DataGrids, which are essential for displaying and managing data.
.NET 8: .NET 8
is the latest version of the .NET framework
, which includes enhancements and new features that improve performance, security, and developer productivity.
Inline Editing: Users can edit directly within the grid
, which simplifies the editing process
.
index.razor
index.razor
@page "/BlogPost"
<PageTitle>Posts</PageTitle>
<RadzenRow>
<RadzenColumn SizeSM="12" SizeMD="12" SizeLG="4">
<RadzenStack Orientation="Orientation.Horizontal" AlignItems="AlignItems.Center">
<RadzenText Text="Posts" TextStyle="TextStyle.H5" />
@* <RadzenButton Text="Create" Icon="add_circle_outline"
Click="NavigatetoCreate"
ButtonStyle="ButtonStyle.Success" class="rz-mb-2 rz-p-2" /> *@
</RadzenStack>
</RadzenColumn>
</RadzenRow>
<RadzenDataGrid @ref="blogPostsGrid" KeyProperty="Id" IsLoading="@isLoading" Count="@totalCount" ShowPagingSummary=true AllowAlternatingRows="false" AllowFiltering="true" FilterMode="FilterMode.Advanced" FilterCaseSensitivity="FilterCaseSensitivity.CaseInsensitive" AllowPaging="true" PagerHorizontalAlign="HorizontalAlign.Center" PageSize="@itemPageSize" AllowSorting="true" EditMode="DataGridEditMode.Single" Data="@blogPosts" TItem="BlogPostViewModel" LoadData="@LoadData" RowUpdate="@OnUpdateRow" RowCreate="@OnCreateRow" Sort="@Reset" Page="@Reset" Filter="@Reset">
<HeaderTemplate>
<RadzenButton ButtonStyle="ButtonStyle.Success" Icon="add_circle" Text="Add New Post" Click="@InsertRow" Disabled="@(blogPostsToInsert.Count() > 0)" />
</HeaderTemplate>
<Columns>
<RadzenDataGridColumn TItem="BlogPostViewModel" Property="Id" Filterable="false" Title="Id" Frozen="true" Width="50px" MinWidth="50px" TextAlign="TextAlign.Center" />
<RadzenDataGridColumn TItem="BlogPostViewModel" Property="Title" Title="Title">
<EditTemplate Context="blogPost">
<RadzenTextBox @bind-Value="blogPost.Title" Name="Title" style="width: 100%" aria-label="Enter Title" />
<RadzenRequiredValidator Text="Title is required" Component="Title" Popup="true" />
</EditTemplate>
</RadzenDataGridColumn>
<RadzenDataGridColumn TItem="BlogPostViewModel" Property="Content" Title="Content">
<EditTemplate Context="blogPost">
<RadzenTextBox @bind-Value="blogPost.Content" Name="Content" style="width: 100%" aria-label="Enter Content" />
<RadzenRequiredValidator Text="Content is required" Component="Content" Popup="true" />
</EditTemplate>
</RadzenDataGridColumn>
<RadzenDataGridColumn Context="blogPost" Filterable="false" Sortable="false" TextAlign="TextAlign.Right" Frozen="true" FrozenPosition="FrozenColumnPosition.Right" Width="140px" MinWidth="140px">
<Template Context="blogPost">
<RadzenButton Icon="add_circle" ButtonStyle="ButtonStyle.Success" Variant="Variant.Flat" Size="ButtonSize.Medium" Shade="Shade.Lighter" Click="@(() => InsertAfterRow(blogPost))" title="Add new row after this row" Disabled="@(blogPostsToInsert.Count() > 0)" />
<RadzenButton Icon="edit" ButtonStyle="ButtonStyle.Light" Variant="Variant.Flat" Size="ButtonSize.Medium" class="rz-my-1 rz-ms-1" Click="@(args => EditRow(blogPost))" @onclick:stopPropagation="true" />
<RadzenButton Icon="delete" ButtonStyle="ButtonStyle.Danger" Variant="Variant.Flat" Size="ButtonSize.Medium" Shade="Shade.Lighter" class="rz-my-1 rz-ms-1" Click="@(args => DeleteRow(blogPost))" @onclick:stopPropagation="true" />
</Template>
<EditTemplate Context="blogPost">
<RadzenButton Icon="check" ButtonStyle="ButtonStyle.Success" Variant="Variant.Flat" Size="ButtonSize.Medium" Click="@((args) => SaveRow(blogPost))" aria-label="Save" />
<RadzenButton Icon="close" ButtonStyle="ButtonStyle.Light" Variant="Variant.Flat" Size="ButtonSize.Medium" class="rz-my-1 rz-ms-1" Click="@((args) => CancelEdit(blogPost))" aria-label="Cancel" />
<RadzenButton Icon="delete" ButtonStyle="ButtonStyle.Danger" Variant="Variant.Flat" Size="ButtonSize.Medium" Shade="Shade.Lighter" class="rz-my-1 rz-ms-1" Click="@(args => DeleteRow(blogPost))" aria-label="Delete" />
</EditTemplate>
</RadzenDataGridColumn>
</Columns>
</RadzenDataGrid>
@code {
const int itemPageSize = 10;
private bool isLoading;
private int totalCount;
RadzenDataGrid<BlogPostViewModel>? blogPostsGrid;
private IEnumerable<BlogPostViewModel>? blogPosts;
List<BlogPostViewModel> blogPostsToInsert = new List<BlogPostViewModel>();
List<BlogPostViewModel> blogPostsToUpdate = new List<BlogPostViewModel>();
protected override async Task OnInitializedAsync()
{
await base.OnInitializedAsync();
}
private async Task LoadData(LoadDataArgs args)
{
isLoading = true;
var result = await BlogPostService.GetBlogPostsAsync(filter: args.Filter, top: args.Top, skip: args.Skip, orderby: args.OrderBy, count: true);
blogPosts = Mapper.Map<IEnumerable<BlogPost>, IEnumerable<BlogPostViewModel>>(result.Result);
totalCount = result.TotalCount;
isLoading = false;
}
private void Reset()
{
blogPostsToInsert.Clear();
blogPostsToUpdate.Clear();
}
private void Reset(BlogPostViewModel blogPost)
{
blogPostsToInsert.Remove(blogPost);
blogPostsToUpdate.Remove(blogPost);
}
async Task EditRow(BlogPostViewModel blogPost)
{
if (!blogPostsGrid.IsValid) return;
Reset();
blogPostsToUpdate.Add(blogPost);
await blogPostsGrid.EditRow(blogPost);
}
async Task OnUpdateRow(BlogPostViewModel blogPostViewModel)
{
Reset(blogPostViewModel);
var blogPost = Mapper.Map<BlogPostViewModel, BlogPost>(blogPostViewModel);
bool result = await BlogPostService.UpdateBlogPostAsync(blogPostViewModel.Id, blogPost);
}
async Task SaveRow(BlogPostViewModel blogPost)
{
await blogPostsGrid.UpdateRow(blogPost);
}
async Task CancelEdit(BlogPostViewModel blogPostViewModel)
{
Reset(blogPostViewModel);
blogPostsGrid.CancelEditRow(blogPostViewModel);
await blogPostsGrid.Reload();
}
async Task DeleteRow(BlogPostViewModel blogPost)
{
Reset(blogPost);
if (blogPosts.Any(x => x.Id == blogPost.Id))
{
bool result = await BlogPostService.DeletebyIdAsync(blogPost.Id);
await blogPostsGrid.Reload();
}
else
{
blogPostsGrid.CancelEditRow(blogPost);
await blogPostsGrid.Reload();
}
}
async Task InsertRow()
{
if (!blogPostsGrid.IsValid) return;
Reset();
var blogPost = new BlogPostViewModel();
blogPostsToInsert.Add(blogPost);
await blogPostsGrid.InsertRow(blogPost);
}
async Task InsertAfterRow(BlogPostViewModel row)
{
if (!blogPostsGrid.IsValid) return;
Reset();
var blogPost = new BlogPostViewModel();
blogPostsToInsert.Add(blogPost);
await blogPostsGrid.InsertAfterRow(blogPost, row);
}
async Task OnCreateRow(BlogPostViewModel blogPostViewModel)
{
var blogPost = Mapper.Map<BlogPostViewModel, BlogPost>(blogPostViewModel);
bool result = await BlogPostService.AddBlogPostAsync(blogPost);
blogPostsToInsert.Remove(blogPostViewModel);
await blogPostsGrid.Reload();
}
private void NavigatetoCreate() => NavigationManager.NavigateTo("/BlogPost/Create");
private void NavigatetoDetail(int id) => NavigationManager.NavigateTo($"/BlogPost/Detail/{id}");
private void NavigatetoEdit(int id) => NavigationManager.NavigateTo($"/BlogPost/Edit/{id}");
private void NavigatetoDelete(int id) => NavigationManager.NavigateTo($"/BlogPost/Delete/{id}");
}
The Blazor Radzen DataGrid
implementation for managing blog posts provides a robust solution for inline editing
. By utilizing asynchronous programming and the powerful features of Radzen, developers can create a user-friendly interface that enhances the overall experience of managing blog content
. This approach not only simplifies
data manipulation but also ensures that the application remains responsive and efficient
.
<RadzenDataGridColumn TItem="BlogPostViewModel" Property="Title" Title="Title">
<EditTemplate Context="blogPost">
<RadzenTextBox @bind-Value="blogPost.Title" Name="Title" style="width: 100%" aria-label="Enter Title" />
<RadzenRequiredValidator Text="Title is required" Component="Title" Popup="true" />
</EditTemplate>
</RadzenDataGridColumn>
This column
allows users to edit the title of a blog post inline
. The RadzenTextBox
is bound to the Title property
, and a required validator
ensures that the field is not left empty.
async Task OnUpdateRow(BlogPostViewModel blogPostViewModel)
{
Reset(blogPostViewModel);
var blogPost = Mapper.Map<BlogPostViewModel, BlogPost>(blogPostViewModel);
bool result = await BlogPostService.UpdateBlogPostAsync(blogPostViewModel.Id, blogPost);
}
This method handles the update
operation when a user modifies a blog post. It maps the view model to the domain model and calls the service to persist changes.
Source
Full source code is available at this repository in GitHub:
https://github.com/akifmt/DotNetCoding/tree/main/src/BlazorAppRadzenNet8DataGridInLineEdit
